Product Introduction
All-Position Triangle TR656 Truck Tire is designed for regional operation, delivering reliable performance on both wet and dry roads.
Product Parameter (Specification)
| Size | LI/SS | PR | Rim size | Inflated Section width (mm) | Overall diameter (mm) | Radius under load (mm) | Load capacity (kg/lbs) - Single | Load capacity (kg/lbs) - Dual | IP kpa | IP Psi | OTD (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST235/85R16 | 129/125L | 14 | 6.5 | 235 | 806 | — | 1850/4080 | 1650/3640 | 750 | 110 | 10.5 |
| LT235/85R16 | 126/123L | 14 | 6.5 | 235 | 806 | 373 | 1700/3750 | 1550/3415 | 750 | 110 | 10.5 |
| 8.5R17.5 | 121/120M | 12 | 6 | 215 | 802 | 374 | 1450/3195 | 1400/3085 | 625 | 90 | 12 |
| 8.5R17.5 | 121/120L | 12 | 6 | 215 | 802 | 374 | 1450/3195 | 1400/3085 | 625 | 90 | 12 |
| 9.5R17.5 | 129/127L | 14 | 6.75 | 240 | 842 | 391 | 1850/4080 | 1750/3860 | 750 | 109 | 14 |
| 9.5R17.5 | 143/141J | 18 | 6.75 | 240 | 842 | 391 | 2725/6005 | 2575/5675 | 875 | 127 | 14 |
| 8R19.5 | 124/122K | 12 | 6 | 203 | 859 | 402 | 1600/3525 | 1500/3305 | 760 | 110 | 13 |
| 8R19.5 | 127/125L | 14 | 6 | 203 | 859 | 402 | 1750/3860 | 1650/3640 | 850 | 125 | 13 |
Product Feature And Application
Feature:
· Enhanced wet/dry traction with zigzag siping grooves
· Even wear & longer life with scrub-resistant closed shoulders
· Durable casing for improved retreadability and economy
Application：
All-Position Truck Tire Triangle TR656, designed for regional commercial trucks.
Production Details
Core Advantages of All-Position Truck Tire Triangle TR656
· Superior wet/dry traction with zigzag siping grooves for reliable all-weather performance
· Even wear & cornering scrub resistance via wide closed shoulder ribs, extending service life
· Reinforced casing boosts toughness and retreadability, lowering total operation cost
