AD713 are drive axle tires designed for heavy trucks and tank trailers operating on paved highway roads.
| Tire Size | LR/PR | Service Index | Tread Depth (mm) | Standard Rim | Overall Diameter (mm) | Section Width (mm) | Single Load (kg) | Single Load (lbs) | Single Inflation Pressure (kPa) | Single Inflation Pressure (psi) | Dual Load (kg) | Dual Load (lbs) | Dual Inflation Pressure (kPa) | Dual Inflation Pressure (psi) |
| 11R22.5(AD713) | G/14 | 144/142 L | 22.6 | 8.25 | 1065 | 279 | 2800 | 6175 | 720 | 105 | 2650 | 5840 | 720 | 105 |
| 11R22.5(AD713) | H/16 | 148/145L | 22.6 | 8.25 | 1065 | 279 | 3150 | 6940 | 850 | 123 | 2900 | 6390 | 850 | 123 |
| 12R22.5(AD713/AD751) | J/18 | 152/149L | 23 | 9 | 1096 | 300 | 3550 | 7830 | 930 | 135 | 3250 | 7160 | 930 | 135 |
| 275/70R22.5(AD713) | H/16 | 148/145L | 18.5 | 8.25 | 958 | 276 | 3150 | 6940 | 900 | 130 | 2950 | 6395 | 900 | 130 |
| 295/80R22.5(AD713) | H/16 | 150/147M | 20 | 9 | 1050 | 298 | 3350 | 7390 | 930 | 130 | 3075 | 6780 | 930 | 130 |
| 295/80R22.5(AD713) | J/18 | 152/149M | 20 | 9 | 1050 | 298 | 3550 | 7830 | 900 | 130 | 3250 | 7160 | 900 | 130 |
| 315/80R22.5(AD713/AD751) | J/18 | 154/151M(156/150L) | 22.5 | 9 | 1082 | 312 | 3750 | 8270 | 930 | 130 | 3750 | 8270 | 930 | 130 |
| 315/80R22.5(AD713) | L/20 | 157/154K | 22.5 | 9 | 1076 | 312 | 4125 | 9090 | 900 | 130 | 3750 | 8270 | 900 | 130 |
Product Features
Ultra-deep robust block tread delivers reliable wet traction and extended service life
Designed for drive axles, offering stable lateral support and multiple retread capacity
Advanced carcass tech ensures uniform footprint and strengthens damage resistance
Available production: Made in China & Thailand
Chaoyang AD713 Drive Axle Tire is recommended axle: Drive axle, matches dry van semi-trailers and tank trucks, for full-paved long-distance highway freight transport, delivering ultra deep tread with robust tread blocks features excellent wet traction and longer tyre life, drive axle applicable providing lateral stability and multiple retreads, latest carcass technology guarantees superior footprint and enhances damage resistance.
Recommended axle: Drive axle
Matches dry van semi-trailers and tank trucks
For full-paved long-distance highway freight transport
Core Advantages of Chaoyang AD713 Drive Position
1.Ultra deep tread with robust tread blocks features excellent wet traction and longer tyre life
2.Drive axle applicable providing lateral stability and multiple retreads
3.Latest carcass technology guarantees superior footprint and enhances damage resistance
