Chaoyang AZ687 All Position Suitable for urban roads

Model:Chaoyang/AZ687

Chaoyang AZ687 All Position tyre features optimized wide‑rib deep tread for outstanding mileage. Zig‑zag grooves guarantee reliable traction and braking, while 3D siping promotes even wear. Robust sidewall protection reduces scuff damage during frequent turning and braking for city‑vehicle operations.

Send Inquiry

Product Description

Chaoyang AZ687

AZ687 is a regional steer/all-position tire designed for buses and trucks, featuring deep tread depth for outstanding mileage performance .


Product Parameter (Specification)

Size	LR / PR	Service Index	Tread Depth (mm)	Overall Diameter (mm)	Section Width (mm)	Max. Load Capacity at Cold Inflation Pressure - Single (kg)	Max. Load Capacity at Cold Inflation Pressure - Single (lbs)	Max. Load Capacity at Cold Inflation Pressure - Single (kPa)	Max. Load Capacity at Cold Inflation Pressure - Single (psi)	Max. Load Capacity at Cold Inflation Pressure - Dual (kg)	Max. Load Capacity at Cold Inflation Pressure - Dual (lbs)	Max. Load Capacity at Cold Inflation Pressure - Dual (kPa)	Max. Load Capacity at Cold Inflation Pressure - Dual (psi)
11R22.5	G/14	144/142J	20.6	1065	279	2800	6175	720	105	2650	5840	720	105
11R22.5	H/16	148/145J	20.6	1065	279	3150	6940	850	123	2900	6390	850	123

Features of Chaoyang AZ687

Four‑rib tread pattern, delivers even wear and reliable traction on wet & dry roads
Deep wide tread design, extends mileage for long service life
Reinforced shoulder plus steel sidewall, improves casing durability and retread‑ability
Sidewall protective ribs, resists sidewall scuff damage during turning, backing and braking for urban operation
Cool‑running compound reduces rolling resistance for better fuel efficiency
Dual‑origin supply: Made in China & Thailand

Application

Recommended for city buses, urban coaches and highway heavy‑duty trucks
Suitable for urban stop‑go traffic and long‑haul highway transport
Size range:11R22.5‑295/80R22.5, covers multiple bus & truck fitment

Production Details

Core Advantages of Chaoyang AZ687 All Position Suitable for urban roads

1.Stable performance for city transportation
2.Long mileage with excellent wear resistance
3.Precise handling and vehicle stability
4.Enhanced wet-road grip and safety
5.Low rolling resistance with comfortable driving experience
