Product Introduction
Triangle Tire-TR688 Commercial Truck Tire is a Drive tyre.Helping reduce inventory complexity and improve fleet efficiency. It is engineered for both on-road and light off-road applications, such as regional highways, urban roads, construction access roads, and mixed gravel or semi-rough surfaces.
Product Parameter
| Size | LI/SS | PR | Rim size | Rim Alternative | Inflated Section width (mm) | Overall diameter (mm) | Radius under load (mm) | Load capacity kg/lbs - Single | Load capacity kg/lbs - Dual | IP - kPa | IP - psi | OTD (mm) |
| 11R22.5 | 146/143M | 16 | 8.25 | 7.5 | 279 | 1054 | 491 | 3000 / 6610 | 2725 / 6005 | 830 | 120 | 18 |
| 12R22.5 | 152/149K | 18 | 9 | 8.25 | 300 | 1085 | 504 | 3550 / 7830 | 3250 / 7160 | 930 | 135 | 20 |
| 11R24.5 | 146/143M | 14 | 8.25 | 7.5 | 279 | 1104 | 516 | 3000 / 6610 | 2725 / 6005 | 720 | 105 | 18 |
| 11R24.5 | 149/146M | 16 | 8.25 | 7.5 | 279 | 1104 | 516 | 3250 / 7160 | 3000 / 6610 | 830 | 120 | 18 |
| 295/80R22.5 | 152/148M | 16 | 9 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3150 / 6945 | 850 | 125 | 18 |
| 295/80R22.5 | 152/149L | 18 | 9 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3250 / 7160 | 900 | 130 | 18 |
| 315/80R22.5 | 151/148M | 16 | 9 | 9.75 | 312 | 1076 | 500 | 3450 / 7610 | 3150 / 6940 | 760 | 110 | 20 |
| 315/80R22.5 | 154/151M | 18 | 9 | 9.75 | 312 | 1076 | 500 | 3750 / 8270 | 3450 / 7610 | 830 | 120 | 20 |
| 315/80R22.5 | 157/154L | 20 | 9 | 9.75 | 312 | 1076 | 500 | 4125 / 9090 | 3750 / 8270 | 900 | 130 | 20 |
Feature:
Mixed road performance – designed for both on-road highways and light off-road conditions such as gravel and construction sites
Enhanced durability – deep tread pattern and reinforced structure provide longer mileage and extended service life
Improved cut & chip resistance – special tread compound helps resist damage in harsh working environments
Stable handling performance – optimized tread design ensures better vehicle control and driving stability
Even wear design – helps reduce irregular wear and improves overall tire longevity
Application：
Triangle Tire-TR688 Commercial Truck Drive Tire is suitable for On-road highways and light off-road conditions such as gravel and construction sites.
Production Details
Core Advantages of Wheel Tyres TR688 Drive Tires
1.Deep tread pattern
2. Better braking performance
3. Excellent grip
4. Strong traction on rough terrain
5. R&D and Certification Systems: Participates in Chinese tire standard development; holds international certifications (U.S. DOT, EU ECE, etc.).
6. Adaptability to Complex Road Conditions
