Product Introduction
Triangle Tire-TRD06
Triangle Tyres TRD06 Commercial Truck Tire is a drive tyre built for mixed and harsh terrains. Suitable for construction, mining, and regional transport, TRD06 delivers consistent performance and extended durability.
Product Parameter
| Size | LI/SS | PR | Rim size | Rim Alternative | Inflated Section width mm | Overall diameter mm | Radius under load mm | Load capacity Single (kg/lbs) | Load capacity Dual (kg/lbs) | IP kPa | IP psi | OTD mm |
| 9.5R17.5 | 136/134M | 18 | 6.75 | 6 | 240 | 842 | 391 | 2240 / 4940 | 2120 / 4675 | 900 | 130 | 16 |
| 11R22.5 | 146/143M | 16 | 8.25 | 7.5 | 279 | 1054 | 491 | 3000 / 6610 | 2725 / 6005 | 830 | 120 | 20.5 |
| 12R22.5 | 152/149K | 18 | 9 | 8.25 | 300 | 1085 | 504 | 3550 / 7830 | 3250 / 7160 | 930 | 135 | 21.5 |
| 295/80R22.5 | 152/149K | 18 | 9 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3250 / 7160 | 900 | 130 | 20 |
| 295/80R22.5 | 152/148L | 16 | 9 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3150 / 6945 | 850 | 125 | 20 |
| 295/80R22.5 | 152/149L | 18 | 9 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3250 / 7160 | 900 | 130 | 20 |
| 315/80R22.5 | 154/151L | 18 | 9 | 9.75 | 312 | 1076 | 500 | 3750 / 8270 | 3450 / 7610 | 830 | 120 | 20 |
| 315/80R22.5 | 156/150L | 18 | 9 | 9.75 | 312 | 1076 | 500 | 4000 / 8820 | 3350 / 7390 | 875 | 127 | 20 |
| 315/80R22.5 | 157/154K | 20 | 9 | 9.75 | 312 | 1076 | 500 | 4125 / 9090 | 3750 / 8270 | 900 | 130 | 20 |
| 245/70R19.5 | 133/131M | 14 | 7.5 | 6.75 | 248 | 839 | 391 | 2060 / 4540 | 1950 / 4300 | 760 | 110 | 16.5 |
| 245/70R19.5 | 135/133L | 16 | 7.5 | 6.75 | 248 | 839 | 391 | 2180 / 4805 | 2060 / 4540 | 830 | 120 | 16.5 |
| 245/70R19.5 | 136/134M | 16 | 7.5 | 6.75 | 248 | 839 | 391 | 2240 / 4940 | 2120 / 4675 | 830 | 120 | 16.5 |
| 245/70R19.5 | 141/140J | 18 | 7.5 | 6.75 | 248 | 839 | 391 | 2575 / 5675 | 2500 / 5510 | 850 | 125 | 16.5 |
| 265/70R19.5 | 137/134L | 14 | 7.5 | 8.25 | 262 | 867 | 402 | 2300 / 5070 | 2120 / 4675 | 760 | 110 | 16 |
| 265/70R19.5 | 140/138L | 16 | 7.5 | 8.25 | 262 | 867 | 402 | 2500 / 5510 | 2360 / 5205 | 775 | 112 | 16 |
| 265/70R19.5 | 140/138M | 16 | 7.5 | 8.25 | 262 | 867 | 402 | 2500 / 5510 | 2360 / 5205 | 775 | 112 | 16 |
| 265/70R19.5 | 143/141J | 18 | 7.5 | 8.25 | 262 | 867 | 402 | 2725 / 6005 | 2575 / 5675 | 850 | 123 | 16 |
| 305/70R19.5 | 144/141M | 14 | 9 | 8.25 | 305 | 923 | 425 | 2800 / 6175 | 2575 / 5675 | 760 | 110 | 19 |
| 305/70R19.5 | 146/143M | 18 | 9 | 8.25 | 305 | 923 | 425 | 3000 / 6610 | 2725 / 6005 | 830 | 120 | 19 |
| 305/70R19.5 | 148/145M | 20 | 9 | 8.25 | 305 | 923 | 425 | 3150 / 6940 | 2900 / 6395 | 900 | 130 | 19 |
| 275/70R22.5 | 148/145L | 16 | 8.25 | 9 | 276 | 958 | 446 | 3150 / 6940 | 2900 / 6395 | 860 | 125 | 19 |
| 305/70R22.5 | 150/148M | 18 | 9 | 8.25 | 305 | 1000 | 464 | 3350 / 7390 | 3150 / 6940 | 850 | 123 | 19 |
| 305/70R22.5 | 153/150L | 20 | 9 | 8.25 | 305 | 1000 | 464 | 3650 / 8050 | 3350 / 7390 | 900 | 130 | 19 |
| 315/70R22.5 | 149/146M | 16 | 9 | 9.75 | 312 | 1014 | 469 | 3250 / 7160 | 3000 / 6610 | 760 | 110 | 20 |
| 315/70R22.5 | 151/148M | 18 | 9 | 9.75 | 312 | 1014 | 469 | 3450 / 7610 | 3150 / 6940 | 830 | 120 | 20 |
| 315/70R22.5 | 152/148M(154/150L) | 18 | 9 | 9.75 | 312 | 1014 | 469 | 3550 / 7830 | 3150 / 6940 | 830 | 120 | 20 |
| 295/60R22.5 | 150/147K(149/146L) | 18 | 9 | 9.75 | 292 | 926 | 436 | 3350 / 7390 | 3075 / 6780 | 900 | 130 | 19 |
| 315/60R22.5 | 152/148K | 18 | 9.75 | 9 | 313 | 950 | 447 | 3550 / 7830 | 3150 / 6940 | 900 | 130 | 19.5 |
Feature:
Drive Position Design
Designed for drive axle, delivering strong traction and power transmission in demanding conditions；
Optimized block tread pattern provides excellent grip on mixed, rough, and unpaved roads；
Deep tread depth improves wear resistance and extends service life under heavy-duty usage；
Advantage:
TRD06 Drive Position Commercial Truck Tire offers strong traction and high durability. Reinforced casing and cut-resistant compound enhance resistance to abrasion, cuts, and impacts, ensuring longer service life and reduced downtime.
Application：
Suitable for drive axle of trucks operating on mixed on-road and off-road conditions such as construction, mining, and regional haul.
Production Details
Core Advantages of Wheel Tyres TRD06 Drive Commercial Truck Tires
1. Strong traction and high durability
2. excellent grip on mixed, rough, and unpaved roads
3. Reinforced casing and cut-resistant
4. R&D and Certification Systems: Participates in Chinese tire standard development; holds international certifications (U.S. DOT, EU ECE, etc.).
5. Adaptability to Complex Road Conditions
