Triangle TBR Drive Tire for Long-Haul Trucks LUG Pattern TR918 is a directional drive tire with extra durability for tough unpaved roads application
| Size | LI/SS | PR | Rim Size | Rim Allowance | Inflated Section Width mm | Overall Diameter mm | Radius Under Load mm | Load Capacity kg/lbs (Single) | Load Capacity kg/lbs (Dual) | IP (kpa) | IP (Psi) | OTD mm |
| 7.00R20 | 126/124L | 14 | 5.5 | 6.00,6.00S | 200 | 904 | 422 | 1700/3750 | 1600/3520 | 830 | 120 | 13 |
| 7.50R20 | 130/128L | 14 | 6 | 6.50,6.50T | 215 | 935 | 435 | 1900/4190 | 1800/3970 | 830 | 120 | 13 |
| 10.00R20 | 146/143L | 16 | 7.5 | 7.50V,8.00 | 278 | 1054 | 486 | 3000/6610 | 2725/6005 | 830 | 120 | 15 |
| 10.00R20 | 149/146K | 18 | 7.5 | 7.50V,8.00 | 278 | 1054 | 486 | 3250/7160 | 3000/6610 | 930 | 135 | 15 |
| 11.00R20 | 150/147K | 16 | 8 | 8.50,8.00V | 293 | 1085 | 499 | 3350/7390 | 3075/6780 | 830 | 120 | 16 |
| 11.00R20 | 152/149K | 18 | 8 | 8.50,8.00V | 293 | 1085 | 499 | 3550/7830 | 3250/7160 | 930 | 135 | 16 |
| 12.00R20 | 154/151K | 18 | 8.5 | 8.50V,9.00 | 315 | 1125 | 516 | 3750/8270 | 3450/7610 | 830 | 120 | 16.5 |
| 12.00R20 | 156/153K | 20 | 8.5 | 8.50V,9.00 | 315 | 1125 | 516 | 4000/8820 | 3650/8050 | 900 | 131 | 16.5 |
| 8R22.5 | 130/128M | 14 | 6 | 5.25,6.75 | 203 | 935 | 440 | 1900/4190 | 1800/3970 | 830 | 120 | 13 |
| 11R22.5 | 144/142M | 14 | 8.25 | 7.5 | 279 | 1054 | 491 | 2800/6175 | 2650/5840 | 720 | 105 | 15 |
| 11R22.5 | 146/143M | 16 | 8.25 | 7.5 | 279 | 1054 | 491 | 3000/6610 | 2725/6005 | 830 | 120 | 15 |
| 11R22.5 | 148/144M | 16+ | 8.25 | 7.5 | 279 | 1054 | 491 | /6610 | /5800 | Single:120 | Dual: 110 | 15 |
| 11R22.5 | 148/144M | 18 | 8.25 | 7.5 | 279 | 1054 | 491 | 3150/6940 | 2800/6175 | 930 | 135 | 15 |
| 11R22.5 | 149/146M | 18 | 8.25 | 7.5 | 279 | 1054 | 491 | 3250/7160 | 3000/6610 | 930 | 135 | 15 |
| 12R22.5 | 143/141L | 12 | 9 | 8.25 | 300 | 1085 | 504 | 2725/6005 | 2575/5675 | 620 | 90 | 15 |
| 12R22.5 | 143/141L | 12+ | 9 | 8.25 | 300 | 1085 | 504 | 2725/6005 | 2575/5675 | 620 | 90 | 15 |
| 12R22.5 | 150/147L | 16 | 9 | 8.25 | 300 | 1085 | 504 | 3350/7390 | 3075/6780 | 830 | 120 | 15 |
| 12R22.5 | 152/148L | 16 | 9 | 8.25 | 300 | 1085 | 504 | 3550/7825 | 3150/6945 | 900 | 130 | 15 |
| 12R22.5 | 152/149K | 18 | 9 | 8.25 | 300 | 1085 | 504 | 3550/7830 | 3250/7160 | 930 | 135 | 15 |
| 275/80R22.5 | 149/146M | 16 | 8.25 | 7.5 | 276 | 1012 | 473 | 3250/7160 | 3000/6610 | 850 | 125 | 14 |
| 275/80R22.5 | 149/146L | 18 | 8.25 | 7.5 | 276 | 1012 | 473 | 3250/7160 | 3000/6610 | 900 | 130 | 14 |
| 315/80R22.5 | 154/151M | 18 | 9 | 9.75 | 312 | 1076 | 500 | 3750/8270 | 3450/7610 | 830 | 120 | 15 |
| 315/80R22.5 | 157/154L | 20 | 9 | 9.75 | 312 | 1076 | 500 | 4125/9090 | 3750/8270 | 900 | 130 | 15 |
| 295/75R22.5 | 144/141M | 14 | 9 | 8.25 | 298 | 1014 | 474 | 2800/6175 | 2575/5675 | 760 | 110 | 15 |
| 295/75R22.5 | 146/143M | 16 | 9 | 8.25 | 298 | 1014 | 474 | 3000/6610 | 2725/6005 | 830 | 120 | 15 |
● Special tread compound
● Improved compound tear&cut resistance under off road
● condition
● Long life and wear
● Directional pattern design
● Better traction under off road operation
● Better grip and control
● Stronger bead design
● Prevent bead area issues during off road operation
● Offer better loading capacity
● Unilateral deep grooves with stone ejector
● Longer life and prevent stone pinching
● Mileage and grooves bottom cut resistance
Long-Haul Pattern of commercial truck car
Core Advantages of Triangle TBR Drive Tire for Long-Haul Trucks LUG Pattern TR918
1.High Cost-Effectiveness
2.Outstanding Wear Resistance & Durability
3.Safety Technology
4.Strength in Heavy-Duty Tires
5.R&D and Certification Systems: Participates in Chinese tire standard development; holds international certifications (U.S. DOT, EU ECE, etc.).
6.Adaptability to Complex Road Conditions
| Comparison Dimension | Triangle Tires | International Brands (e.g., Michelin/Continental) | Domestic Brands (e.g., Zhongce Chaoyang) |
| Price | Mid-range, high cost-effectiveness | Premium,significant price premium | Low-end, economical |
| Wear Resistance | Strong, especially in commercial segments | Excellent(leading position) | Moderate to good |
| Comfort & Noise | Good (improved in recent years) | Balanced (excellent noise reduction tech) | Average (focus on durability) |
| Wet Road Performance | Moderate(improved by advanced compounds) | Excellent (advanced silica/monomers) | Moderate |
| Heavy Duty Use | Core strength (strongly reputed) | Technologically advanced but expensive | Strong (cost-effective) |
| Global Brand Image | Well-known domestically, modest globally | Top-tier, globally recognized | Domestically recognized |
