Triangle TR912 Drive Position Truck Tire

Triangle TR912 Drive Position Truck Tire

TRIANGLE TR912 heavy-duty tire features a deepened tread pattern for extended service life, interlocking grooves for superior traction and braking, and a large-block design with specialized compound for excellent puncture and cut resistance. The open wide-groove structure ensures great self-cleaning and heat dissipation, while its high-strength carcass delivers anti-burst and anti-chain damage performance. High load capacity, reliable for heavy-duty use on short-haul trucks, dump trucks, mixed roads and mining sites.

Product Introduction

Triangle Tire-TR912

Triangle TR912 is designed for short-haul trucks and dump trucks, the TRIANGLE TR912 delivers high load capacity, reliable for heavy-duty use across diverse terrains. It performs consistently on national highways, urban-rural roads, construction sites, and mining areas, making it ideal for mixed and harsh working conditions.


Product Parameter (Specification)


Size LI/SS PR Rim size Rim allowance Inflated Section width (mm) Overall diameter (mm) Radius under load (mm) Load capacity Single (kg/lbs) Load capacity Dual (kg/lbs) IP (kpa) IP (Psi) OTD (mm)
9.00R20 144/142F 16 7 7.00T,7.50 259 1030 471 2800/6175 2650/5840 900 130 23
10.00R20 149/146F 18 7.5 7.50V,8.00 278 1065 486 3250/7160 3000/6610 930 135 24
11.00R20 150/147F 16 8 8.50,8.00V 293 1096 499 3350/7390 3075/6780 830 120 24.5
11.00R20 152/149F 18 8 8.50,8.00V 293 1096 499 3550/7830 3250/7160 930 135 24.5
12.00R20 154/151F 18 8.5 8.50V,9.00 315 1136 516 3750/8270 3450/7610 830 120 25.5
12.00R20 156/153F 20 8.5 8.50V,9.00 315 1136 516 4000/8820 3650/8050 900 131 25.5
12.00R20 158/155F 22 8.5 8.50V,9.00 315 1136 516 4250/9370 3875/8540 970 141 25.5
295/80R22.5 152/149J 18 9 8.25 298 1050 487 3550/7825 3250/7160 900 130 22.5

Product Feature And Application


Feature:


  • Deepened tread pattern for extended service life.
  • Interlocking tread blocks and deep grooves deliver superior traction and braking performance.
  • Large-block tread design with a specialized compound enhances puncture and cut resistance.
  • Open wide-groove design provides excellent self-cleaning and heat dissipation.
  • High-strength carcass with reinforced belt layers offers stronger puncture, anti-burst, and anti-chain damage resistance.
  • Ideal for short-haul trucks and dump trucks.
  • Suitable for mixed roads (national highways, urban/rural roads, construction sites) and pure mining conditions.


Application


The TR912 is built with high load capacity, reliable for heavy-duty use on mixed road conditions including national highways, urban/rural roads, construction sites, and pure mining areas.

Suitable for short-haul trucks and dump trucks.


Production Details:

Core Advantages of Triangle Tyres Radial Tire TR912


  1. For short-haul trucks & dump trucks
  2. High load capacity, reliable for heavy-duty use
  3. Works well on highways, construction sites & mining roads
