The TRD02 features an innovative tread design with optimized siping, delivering excellent dry and wet traction as well as even wear for long-distance, regional, and freight trucks.
| Size | LI/SS | PR | Rim size | Rim Alternative | Inflated Section width mm | Overall diameter mm | Radius under load mm | Load capacity Single (kg/lbs) | Load capacity Dual (kg/lbs) | IP kPa | IP psi | OTD mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 295/80R22.5 | 152/148M | 16 | 9.00 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3150 / 6945 | 850 | 125 | 18.0 |
| 295/80R22.5 | 152/148M | 16 | 9.00 | 8.25 | 298 | 1044 | 487 | 3550 / 7825 | 3150 / 6945 | 850 | 125 | 18.0 |
| 295/80R22.5 | 154/151M | 18 | 9.00 | 8.25 | 298 | 1044 | 487 | 3750 / 8270 | 3450 / 7610 | 900 | 130 | 18.0 |
| 295/80R22.5 | 154/151M | 18 | 9.00 | 8.25 | 298 | 1044 | 487 | 3750 / 8270 | 3450 / 7610 | 900 | 130 | 18.0 |
| 315/80R22.5 | 154/151M | 18 | 9.00 | 9.75 | 312 | 1076 | 500 | 3750 / 8270 | 3450 / 7610 | 830 | 120 | 20.0 |
| 315/80R22.5 | 154/151M | 18 | 9.00 | 9.75 | 312 | 1076 | 500 | 3750 / 8270 | 3450 / 7610 | 830 | 120 | 20.0 |
| 315/80R22.5 | 157/154L | 20 | 9.00 | 9.75 | 312 | 1076 | 500 | 4125 / 9090 | 3750 / 8270 | 900 | 130 | 20.0 |
| 315/80R22.5 | 157/154L | 20 | 9.00 | 9.75 | 312 | 1076 | 500 | 4125 / 9090 | 3750 / 8270 | 900 | 130 | 20.0 |
| 285/70R19.5 | 140/137M | 14 | 8.25 | 9.00 | 283 | 895 | 413 | 2500 / 5510 | 2300 / 5070 | 760 | 110 | 16.5 |
| 285/70R19.5 | 144/142M | 16 | 8.25 | 9.00 | 283 | 895 | 413 | 2800 / 6175 | 2650 / 5840 | 830 | 120 | 16.5 |
| 285/70R19.5 | 146/144L | 18 | 8.25 | 9.00 | 283 | 895 | 413 | 3000 / 6610 | 2800 / 6175 | 850 | 123 | 16.5 |
| 285/70R19.5 | 146/144L | 18 | 8.25 | 9.00 | 283 | 895 | 413 | 3000 / 6610 | 2800 / 6175 | 850 | 123 | 16.5 |
| 315/70R22.5 | 149/146M | 16 | 9.00 | 9.75 | 312 | 1014 | 469 | 3250 / 7160 | 3000 / 6610 | 760 | 110 | 16.0 |
| 315/70R22.5 | 151/148M | 18 | 9.00 | 9.75 | 312 | 1014 | 469 | 3450 / 7610 | 3150 / 6940 | 830 | 120 | 16.0 |
| 315/70R22.5 | 152/148M (154/150L) | 16 | 9.00 | 9.75 | 312 | 1014 | 469 | 3550 / 7830 | 3150 / 6940 | 830 | 120 | 16.0 |
| 315/70R22.5 | 152/148M (154/150L) | 16 | 9.00 | 9.75 | 312 | 1014 | 469 | 3550 / 7830 | 3150 / 6940 | 830 | 120 | 16.0 |
1.Ideal for long-distance/regional/freight trucks with premium low-profile design
2.Exceptional dry/wet traction via innovative tread & optimized siping
3.Even wear = longer lifespan + lower operational costs
Application：TRD02 premium low-profile drive tire is specially engineered for long-distance freight trucks and regional transportation trucks, perfectly meeting the operational needs of different freight scenarios.
Core Advantages of Triangle TRD02 TBR Drive Tire
Premium low-profile design: Optimized for long-haul, regional & freight trucks, adaptable to all freight scenarios.
Innovative tread + precision siping: Outstanding dry/wet traction & superior braking performance.
Uniform wear: Extended tire life & reduced fleet operational costs.
