Triangle Radial Truck Tire TRS02 Steer Position

Model:Triangle/TRS02

Triangle Radial Truck Tire TRS02 Steer Position is a high-performance regional haul steer tire built to outlast and outperform. Its enhanced tread compound delivers superior scrub resistance and wear life, while the special sipe design ensures confident wet-road traction and handling. The innovative wavy grooves prevent stone pinching and cracking, keeping the tread intact longer. Built to conquer tough regional routes, it’s engineered for long mileage, reliable grip, and maximum uptime.

Send Inquiry

Product Description

Product Introduction

Triangle Tire-TRS02

Triangle Radial Truck Tire TRS02 Steer Position is a steer position radial truck tire designed for heavy-duty commercial trucks, built for reliable performance on regional haul routes including both dry and wet roads.

Size	LI/SS	PR	Rim Size	Rim Allowance	Inflated Section Width (mm)	Overall Diameter (mm)	Radius Under Load (mm)	Load Capacity (kg/lbs) - Single	Load Capacity (kg/lbs) - Dual	IP (kPa)	IP (Psi)	OTD (mm)
8.25R20	136/134L	14	6.5	6.50T,7.0,7.00T	236	974	452	2240/4940	2120/4675	830	120	14
8.25R20	139/137L	16	6.5	6.50T,7.0,7.00T	236	974	452	2430/5355	2300/5070	930	135	14
10R22.5	141/139M	14	7.5	6.75	254	1019	476	2575/5675	2430/5355	790	115	15
10R22.5	144/142L	16	7.5	6.75	254	1019	476	2800/6175	2650/5840	900	130	15
11R22.5	144/142M	14	8.25	7.5	279	1054	491	2800/6175	2650/5840	720	105	15
11R22.5	146/143M	16	8.25	7.5	279	1054	491	3000/6610	2725/6005	830	120	15
11R22.5	149/146L	18	8.25	7.5	279	1054	491	3250/7160	3000/6610	930	135	15
12R22.5	143/141L	12★★	9	8.25	300	1085	504	2725/6005	2575/5675	620	90	16
12R22.5	150/147L	16	9	8.25	300	1085	504	3350/7390	3075/6780	830	120	16
12R22.5	152/149K	18	9	8.25	300	1085	504	3550/7830	3250/7160	930	135	16
13R22.5	156/153L	18	9.75	9	320	1124	521	4000/8820	3650/8050	875	127	17
13R22.5	156/153L	20	9.75	9	320	1124	521	4000/8820	3650/8050	930	135	17
11R24.5	146/143M	14	8.25	7.5	279	1104	516	3000/6610	2725/6005	720	105	15
11R24.5	149/146M	16	8.25	7.5	279	1104	516	3250/7160	3000/6610	830	120	15
275/80R22.5	149/146M	16	7.5	7.5	276	1012	473	3250/7160	3000/6610	850	125	14
275/80R22.5	149/146L	18	7.5	7.5	276	1012	473	3250/7160	3000/6610	900	130	14
295/80R22.5	152/148M	16	9	8.25	298	1044	487	3550/7825	3150/6945	850	125	16
295/80R22.5	152/149M	18	9	8.25	298	1044	487	3550/7825	3250/7160	900	130	16
295/80R22.5	154/151M	18	9	8.25	298	1044	487	3750/8270	3450/7610	900	130	16
315/80R22.5	154/151M	18	9	9.75	312	1076	500	3750/8270	3450/7610	830	120	16
315/80R22.5	157/154L	20	9	9.75	312	1076	500	4125/9090	3750/8270	900	130	16
295/75R22.5	144/141M	14	9	8.25	298	1014	474	2800/6175	2575/5675	760	110	15
295/75R22.5	146/143M	16	9	8.25	298	1014	474	3000/6610	2725/6005	830	120	15
285/75R24.5	144/141M	14	8.25	—	283	1050	493	2800/6175	2575/5675	760	110	15
265/70R19.5	137/134M	14	7.5	8.25	262	867	402	2300/5070	2120/4675	760	110	14
265/70R19.5	140/138M	16	7.5	8.25	262	867	402	2500/5510	2360/5205	775	112	14
265/70R19.5	143/141J	18	7.5	8.25	262	867	402	2725/6005	2575/5675	850	123	14
255/70R22.5	140/137M	16	7.5	—	255	930	435	2500/5510	2300/5070	830	120	14.5
275/70R22.5	148/145L	16	8.25	9	276	958	446	3150/6940	2900/6395	860	125	17
275/70R22.5	152/148J	18	8.25	9	276	958	446	3550/7830	3150/6940	930	135	17
305/70R22.5	150/148M	18	9	8.25	305	1000	464	3350/7390	3150/6940	850	123	15
305/70R22.5	153/150L	20	9	8.25	305	1000	464	3650/8050	3350/7390	900	130	15
315/70R22.5	151/148M	18	9	9.75	312	1014	469	3450/7610	3150/6940	830	120	15
315/70R22.5	152/148M(154/150L)	16	9	9.75	312	1014	469	3550/7830	3150/6940	830	120	15

Product Feature And Application：

Optimized for steer axles of medium & heavy-duty trucks
Enhanced tread compound for excellent scrub resistance and longer service life
Special sipe design provides stable handling and reliable wet-road traction
Wavy grooves effectively prevent stone drilling and tread cracking
Suitable for regional transportation with stable performance and even wear

Application：The Triangle TRS02 steer tire is designed for medium and heavy-duty commercial trucks used in regional transportation.

Core Advantages of Triangle Radial Truck Tire TRS02 Steer Position

Strong scrub resistance and long service life
Excellent wet grip and stable handling performance
Wavy grooves avoid stone trapping and tread cracking
Ensures even wear for regional haul operations
