Product Introduction
Triangle Tire-TRS03
TRS03 is a steer axle tyre, mainly used for trucks running on highways and good road conditions, offering stable handling and long mileage.
Product Parameter
| Size | LI/SS | PR | Rim size | Rim Alternative | Inflated Section width (mm) | Overall diameter (mm) | Radius under load (mm) | Load capacity - Single (kg) | Load capacity - Single (lbs) | Load capacity - Dual (kg) | Load capacity - Dual (lbs) | IP kPa | IP psi | OTD (mm) |
| 11R22.5 | 144/142M | 14 | 8.25 | 7.5 | 279 | 1054 | 491 | 2800 | 6175 | 2650 | 5840 | 720 | 105 | 16.5 |
| 11R22.5 | 146/143M | 16 | 8.25 | 7.5 | 279 | 1054 | 491 | 3000 | 6610 | 2725 | 6005 | 830 | 120 | 16.5 |
| 12R22.5 | 150/147L | 16 | 9 | 8.25 | 300 | 1085 | 504 | 3350 | 7390 | 3075 | 6780 | 830 | 120 | 17.5 |
| 12R22.5 | 152/149K | 18 | 9 | 8.25 | 300 | 1085 | 504 | 3550 | 7830 | 3250 | 7160 | 930 | 135 | 17.5 |
| 295/80R22.5 | 152/149M | 18 | 9 | 8.25 | 298 | 1044 | 487 | 3550 | 7825 | 3250 | 7160 | 900 | 130 | 13.5 |
| 295/80R22.5 | 154/151M | 18 | 9 | 8.25 | 298 | 1044 | 487 | 3750 | 8270 | 3450 | 7610 | 900 | 130 | 13.5 |
| 315/80R22.5 | 154/151M | 18 | 9 | 9.75 | 312 | 1076 | 500 | 3750 | 8270 | 3450 | 7610 | 830 | 120 | 13.5 |
| 315/80R22.5 | 157/154L | 20 | 9 | 9.75 | 312 | 1076 | 500 | 4125 | 9090 | 3750 | 8270 | 900 | 130 | 13.5 |
| 315/60R22.5 | 152/148K | 18 | 9.75 | 9 | 313 | 950 | 447 | 3550 | 7830 | 3150 | 6940 | 900 | 130 | 13.5 |
Product Feature And Application
Feature:
1. High scrub resistance design
2.Larger contact patch with extra tread rubber.
3.Optimized shoulder structure
4.Improved traction pattern with noise control
Advantage:
Tyres TRS03 Steer Commercial Truck Tire ,Strong design for long mileage, even wear, and comfortable, stable driving performance.
Application：Designed for steer axle use on long-haul and regional trucks, mainly for highways and well-paved roads.
Core Advantages of Triangle Tyres TRS03 Steer Commercial Truck Tires
1.Larger contact patch with extra tread rubber
2.Improved traction pattern with noise control
3.Better grip and extended wear life
4.Comfortable driving with lower noise
5. R&D and Certification Systems: Participates in Chinese tire standard development; holds international certifications (U.S. DOT, EU ECE, etc.).
